Automatic Air Bubble Poly Film Cutting Machine

The All-New HZX Series: Automatic Air Bubble Wrap and Film Cutters - Achieve Efficiency and Precision in Film Cutting Operations

The HZX Series Automatic Air Bubble Wrap and Film Cutters establish a new standard for efficiency and  accuracy in film cutting applications.

Effortless Operation, Exceptional Results:

High-Speed Performance: Experience cutting speeds of 100-120 cuts per minute (at 50mm length) for maximized production output.

Unmatched Precision: Cut lengths are controlled by a reliable stepping motor, ensuring consistent and accurate results every single time.

Clean and Neat Cuts: The durable cold cutter delivers clean, precise cuts without fraying, ideal for various film materials.

User-Friendly Controls: The intuitive interface allows for easy setting of cutting length, quantity, and speed for automated operation.

Automatic Functions: The machine automatically stops when materials run out, preventing errors and wasted materials.

Versatility and Advanced Features:

Suitable for Various Materials: Perfectly cuts air bubble wrap, films, sheets, sleeves, rubber/plastic tubes, small wires, and more.

Cold or Hot Cut Options: Choose between cold cutting for standard applications or hot cutting (available on HZX-800 model only) to prevent fraying on nylon, polyester, and braided webbing materials.

Memory Function: The machine remembers setting information (length, quantity, speed) even after power off, enhancing user convenience.

Technical Specifications:

Model No. Cutter Type Voltage Power Cutting Width Cutting Length Cutting Speed Cutting Accuracy Weight Roller Spec. Dia. Dimension (L x W x H)

HZX-400 Top and Bottom Blade Cutter 110/220V 0.75 KW 1-400 mm 1-9999 mm 0-999 ±0.1 mm 55 kg Dia. 20-76 800 x 650 x 390 mm

HZX-500 Top and Bottom Blade Cutter 110/220V 0.8 KW 1-500 mm 1-9999 mm 0-999 ±0.1 mm 75 kg Dia. 20-76 800 x 750 x 390 mm

HZX-600 Top and Bottom Blade Cutter 110/220V 0.95 KW 1-600 mm 1-9999 mm 0-999 ±0.1 mm 85 kg Dia. 20-76 800 x 850 x 390 mm

HZX-700 Top and Bottom Blade Cutter 110/220V 0.95 KW 1-700 mm 1-9999 mm 0-999 ±0.1 mm 95 kg Dia. 20-76 800 x 950 x 390 mm

HZX-800 Top and Bottom Blade Cutter 110/220V 1.1 KW 1-800 mm 1-9999 mm 0-999 ±0.1 mm 105 kg Dia. 20-76 800 x 1050 x 390 mm

The HZX Series Automatic Air Bubble Wrap and Film Cutters  are perfect solutions for businesses seeking to  streamline and elevate their film cutting processes.  Their exceptional speed, precision,  user-friendly features, and material versatility  make them valuable assets for any production line  working with air bubble wrap, films, and various  other sheet materials.
